Do you know where the Carter C4.2 engine sensor is? Come and get to know it

Do you know where the Carter C4.2 engine sensor is? Come and get to know it

The C4.2 Engine Electronic Control Module (ECM) and sensors are located on the left side of the engine. Sensor locations on the Carter C4.2 engine:

(1) Intake manifold (supercharging) pressure sensor;

(2) Intake manifold temperature sensor;

(3) Coolant temperature sensor;

(4) Main speed/timing sensor;

(5) Oil pressure sensor;

(6) Fuel differential pressure sensor;

(7) Fuel temperature sensor;

(8) Fuel pressure sensor

(9) Fuel rail pressure sensor;

(10) Solenoid valve of fuel rail pump;

(11) Auxiliary speed/timing sensor;

A detailed view of the sensor locations on the Carter C4.2 engine:

(1) Intake manifold (supercharging) pressure sensor;

(2) Intake manifold temperature sensor;

(3) Coolant temperature sensor;

(6) Fuel differential pressure sensor;

(7) Fuel temperature sensor;

(8) Fuel pressure sensor;

(7) Fuel temperature sensor;

(8) Fuel pressure sensor;

(9) Fuel rail pressure sensor;

(10) Solenoid valve of fuel rail pump;

(11) Auxiliary speed/timing sensor;
